Supravox赛博威声 165EXC 7英寸全频喇叭
|
165EXC 全频喇叭参数 |
|||
|
Efficiency 1W/1m at Fs 效率 1W/1m at Fs |
90~95dB |
Sd |
165cm2 |
|
Frequency response 频响 |
60~20kHz |
Fs |
65Hz |
|
Impedance 阻抗 |
4Ω |
Mms |
5g |
|
Power max. RMS 最大不失真功率 |
35W |
Cms |
1.19 |
|
Weight 重量 |
3.2kg |
Re DC |
4.1Ω |
|
Suspension 悬边 |
5层纸摺边 |
|
|
|
Resonance frequency 谐振频率 |
65Hz |
|
|
|
Linear excursion 线性位移 |
± 5mm |
|
|
|
Power supply 电量供给 |
0~10伏 CC. |
|
|
|
Magnetic field 磁通量 |
0~2T |
|
|
|
Diameter HP 喇叭直径 |
185mm |
|
|
|
Frame thickness 盆架安装高度 |
铝合金 10mm |
|
|
|
Diameter fixation holes 安装直径 |
175mm |
|
|
|
Diameter drilling enclosure 箱体开孔直径 |
160mm |
|
|
|
Depth HP 喇叭深度 |
95mm |
|
|
|
备注： 上述之参数及曲线图由LAUD2软件测量所得，均由Supravox原厂提供。 |
|||
|
零售价RMB：￥15,048/对pair |
|||
|
165EXC 全频喇叭参数
|
|||
|
Efficiency 1W/1m at Fs
效率 1W/1m at Fs
|
90~95dB
|
Sd
|
165cm2
|
|
Frequency response
频响
|
60~20kHz
|
Fs
|
65Hz
|
|
Impedance
阻抗
|
4Ω
|
Mms
|
5g
|
|
Power max. RMS
最大不失真功率
|
35W
|
Cms
|
1.19
|
|
Weight
重量
|
3.2kg
|
Re DC
|
4.1Ω
|
|
Suspension
悬边
|
5层纸摺边
|
|
|
|
Resonance frequency
谐振频率
|
65Hz
|
|
|
|
Linear excursion
线性位移
|
± 5mm
|
|
|
|
Power supply
电量供给
|
0~10伏 CC.
|
|
|
|
Magnetic field
磁通量
|
0~2T
|
|
|
|
Diameter HP
喇叭直径
|
185mm
|
|
|
|
Frame thickness
盆架安装高度
|
铝合金 10mm
|
|
|
|
Diameter fixation holes
安装直径
|
175mm
|
|
|
|
Diameter drilling enclosure
箱体开孔直径
|
160mm
|
|
|
|
Depth HP
喇叭深度
|
95mm
|
|
|
|
备注：
上述之参数及曲线图由LAUD2软件测量所得，均由Supravox原厂提供。
|
|||
|
零售价RMB：￥15,048/对pair
|
|||
