瑞士 Goldmund高文 Mimesis PH3.8 NextGen唱放
GAIN MM INPUT
43 dB (low) and 50 dB (high).
GAIN MC INPUT
63 dB (low) and 70 dB (high).
RIAA CURVE
– 0.03 dB / + 0.06 dB max derivation from RIAA curve.
GAIN STAGE RESPONSE
– 3 dB 0.12 Hz – 760 kHz at 70 dB gain (without RIAA correction).
SLEW RATE
80 V/us.
RISE TIME
< 400 ns.
DISTORTION
< 0.007 % (20 Hz-20 kHz at 4 Vrms output).
OUTPUT IMPEDANCE
50 Ohms.
MAX OUTPUT LEVEL
32 Vpp Power.
SIZE
PREAMPLIFIER & POWER SUPPLY
44 W x 38.6 D x 13.2 H (cm).
WEIGHT
PREAMPLIFIER
10 kg.
POWER SUPPLY
12 kg.
