设计

5-driver, 2-way acoustic suspension, LCR, on-wall / stand / shelf-mounted

分频器

2nd-order electro-acoustic at 2.0 kHz

频率响应   On-Axis

±2 dB from 110 Hz - 20 kHz

频率响应   30° 离轴

±2 dB from 110 Hz - 18 kHz

高音单元

25-mm (1 in) S-PAL™ dome, ferro-fluid damped / cooled, die-cast heatsink chassis

Mid/Bass Frequency Driver

Two 115-mm (4-1/2 in) MLP™ cones, 25-mm (1 in) dual-layer voice-coils, HTD™ system die-cast heatsink chassis

低音单元

Two 115-mm (4-1/2 in) mineral-filled polypropylene cones, 25-mm (1 in) dual-layer voice-coils, HTD™ system die-cast heatsink chassis

低音下潜

77 Hz (DIN)

灵敏度   房间/消声室

92 dB / 89 dB

阻抗

Compatible with 8 ohms

合适的放大器功率范围 Range

15 - 150 watts

最大输入功率

110 watts

颜色

Black Chrome

重量

12.6 lbs. (5.7 kg)

尺寸   高x宽x深

25.875" × 5.125" × 4.625"
(65.8cm × 13.0cm × 11.7cm)
