| 频率响应 |
43Hz-24kHz +/-3dB |
| low frequency extension |
31Hz |
| high frequency extension |
30kHz |
| 承载功率 |
275W continuous / 1100W peak |
| recommended amplifier power |
50 - 600W |
| 灵敏度 |
96dB @ 2.83V / 1m |
| 标称阻抗 |
4 ohms |
| mid-frequency crossover |
550Hz |
| 高频分频 |
3400Hz |
| 最大声音输出 |
120dB (2 speakers in-room) |
| 高频驱动头 |
0.75" (1.9cm) titanium diaphragm compression driver mated to 90° x 60° Tractrix® Horn |
| mid-frequency drivers |
4.5" (11.4cm) aluminum diaphragm compression driver mated to 90° x 60° Tractrix® Horn |
| 低频驱动头 |
Three 7" (17.8cm) high-output, aluminum / Rohacell® / Kevlar® hybrid cone woofers |
| 机箱材料 |
Constrained layer MDF (medium density fiberboard) |
| 机箱类型 |
Bass-reflex via triple rear-firing ports |
| 高度 |
46.5" (118.1cm) |
| 宽度 |
9.75" (24.8cm) (12" / 30.5cm at the base) |
| 深度 |
19.5" (49.5cm) |
| 重量 |
98 lbs (44.5kg) |
| 饰面 |
Zebra-grain Linia veneer in a natural, merlot or espresso stain |
| 开始生产年份 |
2008 |
