| 频率响应 |
51Hz-24kHz +/-3dB |
| low frequency extension |
40Hz |
| high frequency extension |
30kHz |
| 承载功率 |
150W continuous / 600W peak |
| recommended amplifier power |
50 - 350W |
| 灵敏度 |
94dB @ 2.83V / 1m |
| 标称阻抗 |
4 ohms |
| mid-frequency crossover |
600Hz |
| 高频分频 |
3400Hz |
| 最大声音输出 |
115dB (2 speakers in-room) |
| 高频驱动头 |
0.75" (1.9cm) titanium diaphragm compression driver mated to 90° x 60° Tractrix® Horn |
| mid-frequency drivers |
4.5" (11.4cm) aluminum diaphragm compression driver mated to 90° x 60° Tractrix® Horn |
| 低频驱动头 |
7" (17.8cm) high-output, aluminum / Rohacell® / Kevlar® hybrid cone woofer |
| 机箱材料 |
Constrained layer MDF (medium density fiberboard) |
| 机箱类型 |
Bass-reflex via rear-firing port |
| 高度 |
19.9" (50.6cm) |
| 宽度 |
9.2" (23.4cm) |
| 深度 |
13.5" (34.3cm) |
| 重量 |
30 lbs (13.6kg) |
| 饰面 |
Zebra-grain Linia veneer in a natural, merlot or espresso stain |
| 开始生产年份 |
2008 |
