| 频率响应 |
72Hz-24kHz +/-3dB |
| low frequency extension |
54Hz |
| high frequency extension |
30kHz |
| 承载功率 |
150W continuous / 600W peak |
| recommended amplifier power |
50 - 350W |
| 灵敏度 |
96dB @ 2.83V / 1m |
| 标称阻抗 |
4 ohms |
| 高频分频 |
2000Hz |
| 最大声音输出 |
117dB (2 speakers in-room) |
| 高频驱动头 |
Dual 0.75" (1.9cm) titanium diaphragm compression drivers mated to 90° x 70° Tractrix® Horns in a WDST array |
| 低频驱动头 |
Dual 7" (17.8cm) high-output, aluminum / Rohacell® / Kevlar® hybrid cone woofers |
| 机箱材料 |
CTS composite |
| 机箱类型 |
Bass-reflex via dual front-firing ports |
| 高度 |
20.5" (52.1cm) |
| 宽度 |
13.75" (34.9cm) |
| 深度 |
7" (17.8cm) |
| 重量 |
25 lbs (11.4kg) |
| 饰面 |
Cabinet features a dark smoked nickel satin finish, end caps feature a zebra-grain Linia veneer available in a natural, merlot or espresso stain |
| 开始生产年份 |
2008 |
