| FREQUENCY RESPONSE |
28-120Hz +/-3dB |
| AMPLIFIER POWER |
FTC Rated Power: 200 watts continuous @ 1% THD, Dynamic Power: 420 watts |
| MAXIMUM ACOUSTIC OUTPUT |
115dB @ 30Hz 1/8 space, 1m |
| DRIVE COMPONENTS |
One 10” (25.4cm) fiber-composite cone, down-firing woofer |
| AMPLIFIER |
BASH(r) digital hybrid |
| PHASE |
Switchable 0-180 degrees |
| ENCLOSURE TYPE |
Bass-reflex via rear-firing port |
| INPUTS |
L/R line-level RCA jacks, L/R high level speaker binding posts |
| OUTPUTS |
L/R High level speaker binding posts (passthru) |
| HEIGHT |
17” (43.2cm) H |
| WIDTH |
14” (35.6cm) W |
| DEPTH |
18.9” (47.9cm) D |
| WEIGHT |
37 lbs. (16.8kg) |
| FEATURES |
Volume, Lowpass, Phase, Auto Power |
| FINISHES |
Black vinyl |
| VOLTAGE |
110/120 VAC 60Hz |
| EXPORT VOLTAGE |
220 VAC 50/60Hz |
| BUILT FROM |
2005 |
