| FREQUENCY RESPONSE |
80Hz-20kHz (+-)3dB |
| POWER HANDLING |
100 w max continuous (400 w peak) |
| SENSITIVITY |
94dB @ 2.83 volts / 1 meter |
| NOMINAL IMPEDANCE |
8 ohms compatible |
| CROSSOVER FREQUENCY |
1500Hz |
| TWEETER |
1" (2.5cm) magnetically shielded, titanium dome compression driver with 9.6oz ceramic magnet structure |
| HIGH FREQUENCY HORN |
10" x 6" rectangular 90° x 60° Tractrix® Horn |
| WOOFER |
Two 5.25" (13.3cm) magnetically shielded, Cerametallic™ cone, cast aluminum frame drivers |
| ENCLOSURE MATERIAL |
MDF |
| ENCLOSURE TYPE |
Sealed |
| INPUT CONNECTIONS |
2 sets of binding post speaker terminals (connected via brass strap jumpers) |
| DIMENSIONS |
12.75" (32.4cm) H x 16" (40.6cm) W x 12.5" (31.8cm) D (w/ grille) |
| MOUNTING |
4-bolt pattern, 1/4"-20 thread |
| WEIGHT |
32 lbs. (14.5kg) |
| FINISHES |
Galaxy Black cabinet with Black anodized aluminum fascia |
| BUILT FROM |
2004 |
