| FREQUENCY RESPONSE |
46Hz-20kHz +/-3dB |
| POWER HANDLING |
150W continuous / 600W peak |
| recommended amplifier power |
200W |
| SENSITIVITY |
92dB @ 2.83V / 1m |
| NOMINAL IMPEDANCE |
8 ohms compatible |
| HIGH FREQ CROSSOVER |
2100Hz & 250Hz |
| HIGH FREQUENCY DRIVERS |
1" (2.5cm) Titanium diaphragm compression driver mated to 90° x 90° square Tractrix® Horn |
| LOW FREQUENCY DRIVERS |
Four 5.25" (13.3cm) high-output, fiberglass cone woofers |
| ENCLOSURE MATERIAL |
MDF & Aluminum motorboard / ABS frame |
| ENCLOSURE TYPE |
Infinite baffle, front flush with wall |
| DIMENSIONS |
28.5" (72.4cm) H x 8" (20.3cm) W |
| MOUNTING DEPTH |
3.75" (9.5cm) |
| CUTOUT DIMENSIONS |
27.25" (69.2cm) H x 6.5" (16.5cm) W |
| INSTALLATION KIT |
IK-504-W (sold seperately) |
| WEIGHT |
18.3lbs (8.3kg) |
| FINISHES |
White paintable frame and grille |
| BUILT FROM |
2008 |
