| FREQUENCY RESPONSE |
80Hz-20kHz (+-)3dB |
| POWER HANDLING |
100 w max continuous (400 w peak) |
| SENSITIVITY |
96dB @ 2.83 volts / 1 meter |
| NOMINAL IMPEDANCE |
8 ohms compatible |
| CROSSOVER FREQUENCY |
2100Hz |
| TWEETER |
Two 1" (2.5cm) magnetically shielded, titanium dome compression drivers with neodymium magnet structures |
| HIGH FREQUENCY HORN |
5" square 90° x 60° Tractrix® Horns in a WDST(tm) Array |
| WOOFER |
Two 5.25" (13.3cm) magnetically shielded, Cerametallic™ cone, cast aluminum frame drivers |
| ENCLOSURE MATERIAL |
MDF |
| ENCLOSURE TYPE |
Sealed |
| INPUT CONNECTIONS |
2 sets of binding post speaker terminals (connected via brass strap jumpers) |
| DIMENSIONS |
13.75" (35cm) H x 13" (33cm) W x 8.5" (21.6cm) D |
| MOUNTING |
2-bolt pattern, 1/4"-20 thread |
| WEIGHT |
20 lbs. (9.1kg) |
| FINISHES |
Galaxy Black cabinet with Black anodized aluminum fascia |
| BUILT FROM |
2004 |
