| FREQUENCY RESPONSE |
20-200Hz ±3dB |
| POWER HANDLING |
See KA-1000-THX specifications |
| NOMINAL IMPEDANCE |
8 ohms |
| MAXIMUM ACOUSTIC OUTPUT |
130dB @ 30Hz, 122dB @ 20Hz, 112dB @ 15Hz 1/8 space, 1m (2 enclosures side-by-side per THX Ultra2) |
| WOOFER |
12" (30.5cm) front-firing, Cermetallic(tm) cone, cast aluminum frame driver with a 240oz ceramic magnet structure |
| AMPLIFIER |
Use only with KA-1000-THX |
| ENCLOSURE MATERIAL |
MDF |
| ENCLOSURE TYPE |
Bass reflex via front-firing slot port |
| DIMENSIONS |
20.25" (51.4cm) H x 17.75" (45.1cm) W x 17.75" (45.1cm) D (w/ grille) |
| WEIGHT |
80 lbs. (36.3kg) |
| FINISHES |
Galaxy Black cabinet with Black anodized aluminum fascia |
| BUILT FROM |
2004 |
