| FREQUENCY RESPONSE |
20Hz-1kHz +0/-3dB |
| POWER HANDLING |
FTC Rated Power: 500W into 8 ohms, 1000W into 4 ohms, 20Hz-1kHz @ <1.5% THD / Dynamic Power*: 2050W into 8 ohms, 3025W into 4 ohms @ 5% THD / *Dynamic power indicates the actual power this amplifier w |
| LOW PASS CROSSOVER |
Continuously variable from 40-120Hz, 24dB/octave slope above 120Hz (non-THX mode) |
| AMPLIFIER |
High-Efficiency Class D |
| PHASE |
Continuously variable from 0 to 180 degrees |
| ENCLOSURE TYPE |
Use only with KW-120-THX subwoofer enclosures (either one or two) |
| INPUTS |
2 Gold-plated RCA phono jacks |
| OUTPUTS |
2 Gold-plated RCA phono jacks (unfiltered) / 2 Speakon(r) NL2 jacks |
| AUTO POWER ON |
2 second ON delay, 15 minute OFF delay |
| DIMENSIONS |
4.75" (12.1cm) H x 17.5" (44.5cm) W x 12.25" (31.1cm) D |
| WEIGHT |
27 lbs. (12.3kg) |
| FEATURES |
THX On/Off, Boundary Gain Compensation On/Off |
| FINISHES |
Black anodized aluminum |
| VOLTAGE |
110/120 VAC 60Hz |
| EXPORT VOLTAGE |
230 VAC 50/60Hz |
| BUILT FROM |
2004 |
