SIM AUDIO MOON I-5 合并机

Type	Solid State
Configuration	Dual Mono (partial)
Power Supply Transformer	0.5kVA
Power Supply Capacitance	40,000µF
Class of operation - Preamplifier	A
Class of operation - Amplifier	A/AB
Single Ended Inputs (RCA)	5 pairs
Input Device Types - preamp	J-FET
Input Sensitivity	340mV - 3.0V RMS
Input Impedance	14,000 ohms
Tape Output	1 pair
Preamplifier Output	1 pair
Output Device Types - Amplifier	Bipolars - 2 per channel
Output Binding Posts	WBT (shielded)
Output Power @ 8 ohms	70 Watts per channel
Output Power @ 4 ohms	110 Watts per channel
Output Impedance	0.04 ohms
Damping Factor	> 200
Gain Control	RBG cs version
Gain	37dB
Dynamic Headroom	3dB
Signal-to-noise Ratio	97dB @ full power
Maximum Output Voltage	23.5 Volts
Slew Rate	20V/µs
Maximum Current - Peak	16 amperes
Maximum Current - Continuous	9 amperes
Frequency Response	10Hz - 70kHz (+0/-3dB)
Crosstalk @ 1kHz	-50dB
IMD	unmeasurable
THD (20Hz - 20kHz @ 1 watt)	< 0.1%
