日本 Esoteric K-03X SACD/CD播放机

技术参数：

Compatible disc types	Super Audio CD, CD (CD-R/CD-RW compatible)
Analog audio output	Jacks	XLR jacks (2 channel) x 1
	Jacks	RCA jacks (2 channel) x 1
	Output impedance	XLR: 40Ω
	Output impedance	RCA: 10Ω
	Maximum output leve (1 kHz, full scale, 10 k ohms)	XLR (Gain: 0 dB): XLR: 4.8Vrms
	Maximum output leve (1 kHz, full scale, 10 k ohms)	RCA: 2.4Vrms
	Frequency response	5Hz to 40kHz (-3dB))
	Signal-to-noise ratio (S/N)	116dB
	Total harmonic distortion	0.0001% (1kHz)
Digital audio output	Coaxial RCA jack x 1	0.5 Vp-p/75 ohms
Digital audio input	Coaxial RCA connector x 1	(input impedance 75 ohms)
	Optical digital connector x 1	-24.0 to -14.5 dBm peak
	USB port B connector	USB 2.0 / 192 kHz-24 bit async.
Clock synchronization input format	Jack	BNC
	Input impedance	75 ohms
	Input level	Rectangle wave: equivalent to TTL levels
	Input level	Sine wave: 0.5 to 1.0 Vrms/50 to 75 ohms
	GENERAL
Power supply	Power supply	AC 230 V, 50 Hz AC 120 V, 60 Hz AC 220 V, 60 Hz
	Power consumption	25 W
	External dimensions (W x H x D)	445 x 162 x 438 mm (17 1/4" x 6" 3/8 x 13 1/4") (including protrusions)
	Weight	28 kg (61 3/4 lbs)
	Accessories	Remote control unit (RC-1301) x 1 Batteries (AA) x 2 Power cord set x 1 Felt pads x 3 Owner's manual x 1 Warranty card x 1
