美国威力登CHT-10Q超低音

美国威力登CHT-10Q超低音

  • 本店售价:¥4380元
  • 商品点击数:37338

简单描述:全新行货保修


联系人:李先生 13829461623(微信同号) 业务QQ:1215102187


经销地址:汕头市龙湖区创意音响广场46号2楼42号 中文音响

美国威力登CHT-10Q超低音

Velodyne CHT-10Q
●低音单元口径:1 0 英寸
●内置放大器功率:390W(动态)/195W(持续)
●频率响应: 16~240Hz(Oversall)/28~120Hz(±3dB)
● 分频点调节:40~120Hz连续可调
●相位调节:0º、90º、180º、270º
●尺寸(H×W×D): 406×381×464mm
●重量:25kg

●优点:低频能量充足,音色温暖,速度感良好
●期待:增加XLR输入接口

这款全新的CHT-10Q超低音音箱其实就是之前推出的CHT-10R的升级版。CHT- 10Q与前一代相比,最大的特色就是内置了自动EQ功能,同时保留了前一代产品的所有技术,令这只超低音音箱更加易用。用家只要利用厂家所附带的测试麦克风就能简单地完成测试以及自动参数设置。因此, CHT-10Q可以称得上是一款“傻瓜式”的超低音音箱。除了自动EQ功能之外,CHT- 10Q的内部同样采用了DSP技术。其中, DLS(Distortion Limiting System,失真限制系统)技术无疑是Velodyne最厉害的武器之一。它是通过DSP控制芯片来对低音单元以
及放大器的工作进行实时监测,若检测到异常状况,就会自动作出实时的修正,从而减少低音的失真。与此同时,厂方还在DSP芯片内编写了“Movies”、“R&B Rock”、“Jazz Classical”、“Cames”4种EQ模式以及“Light(日间)”以及“Night(夜间)”2种聆听模式供用家们选择,而这6种模式需要通过遥控器才能进行选择。
除了在内部的功能上面得到扩展外,CHT-10Q还在外型设计以及操作按键方面作了很大改动。首先,CHT-10Q全黑色的箱体设计看上去令人感到更加朴实和耐用。在背板上,CHT-10Q由于采用了效率更高的D类放大器,让发热量大大降低,所以能免除散热器,同时将输出功率提高到195W(RMS),可对低音单元提供更强大的控制力。而且加入了IR Input(线控接口),能够与AV放大器实现联动控制,让用户的操作更方便。



CHT-Q Series

Specifications

CHT-8Q

CHT-10Q

CHT-12Q

CHT-15Q

Amplifier:

(Class D)

360 watts Dynamic

180 watts RMS Power

390 watts Dynamic

195 watts RMS Power

450 watts Dynamic

225 watts RMS Power

1500 watts Dynamic

750 watts RMS Power

Woofer:

8” (20.3 cm)    forward firing

(6.3” piston diameter)

10” (24.5 cm)       forward firing

(8.2” piston diameter)

12” (30.5 cm)  forward firing

(9.7” piston diameter)

15” (38 cm)        forward firing

(12.7”piston diameter)

Magnet Structure:

2.5 lbs

2.5 lbs

3.5 lbs

4.4 lbs

Frequency Response:

Overall

+/- 3 dB

17 – 240 Hz

32 – 120 Hz

16 – 240 Hz

28 – 120 Hz

14.6 – 240 Hz

25 – 120 Hz

14 – 240 Hz

23 – 120 Hz

Voice Coil:

2-Layer copper

2-Layer copper

2-Layer copper

2.5” 4-Layer copper

Cone:

Reinforced fiber

Reinforced fiber

Reinforced fiber

Reinforced fiber

Speaker-Level Pass-Through:

Fixed at 120 Hz high-pass

Fixed at 120 Hz high-pass

Fixed at 120 Hz high-pass

Fixed at 120 Hz high-pass

LowPassCrossover:

40 Hz – 120 Hz adjustable

(12 dB octave,

24 dB ultimate)

40 Hz – 120 Hz adjustable

(12 dB octave,

24 dB ultimate)

40 Hz – 120 Hz adjustable

(12 dB octave,

24 dB ultimate)

40 Hz – 120 Hz adjustable

(12 dB octave,

24 dB ultimate)

Outputs:

Line-Level

Line-Level

Line-Level

Line-Level

Inputs:

Gold plated line-level

Gold plated line-level

Gold plated line-level

Gold plated line-level

Digital Phase:

0º, 90º, 180º, 270º

0º, 90º, 180º, 270º

0º, 90º, 180º, 270º

0º, 90º, 180º, 270º

Cabinet Design:

Extended Excursion Slot-loaded Bass-Reflex

Extended Excursion Slot-loaded Bass-Reflex

Extended Excursion Slot-loaded Bass-Reflex

Extended Excursion Slot-loaded Bass-Reflex

Auto On/Off

Yes

Yes

Yes

Yes

Removable Grille

Yes

Yes

Yes

Yes

Video Shielding

No

No

No

No

LED Display

Yes

Yes

Yes

Yes

Accessories:

Mic, mic stand and remote control

Mic, mic stand and remote control

Mic, mic stand and remote control

Mic, mic stand and remote control

Dimensions (H/W/D):

(cm) with grille

15.25” x 12” x 16.375”

38.7 x 30.5 x 41.6

16” x 15” x 18.25”

40.6 x 38.1 x 46.4

18” x 15” x 19.5”

45.7 x 38.1 x 49.5

21 x 18.375” x 20.75”

53.3 x 46.7 x 52.7

Shipping Weight:

(approx)

44 lbs. (2- kg)

55 lbs. (25 kg)

61 lbs. (28 kg)

75 lbs. (34 kg)

Warranty:

(parts/labor)

Three years (electronics)

Five years (drivers)

Three years (electronics)

Five years (drivers)

Three years (electronics)

Five years (drivers)

Three years (electronics)

Five years (drivers)

Specifications are subject to change without notice.
